| Carga de seguridad | Color | Ancho |
Vertical (M=1) |
Gargantilla (M=0.8) |
0° (M=2) |
45° (M=1.8) |
90° (M=1.4) |
120° (M=1) |
|---|---|---|---|---|---|---|---|---|
| 1T | Morada | 40 mm | 1.0T | 0.8T | 2.0T | 1.8T | 1.4T | 1.0T |
| 2T | Verde | 50 mm | 2,0T | 1,6T | 4,0T | 3,6T | 2,8T | 2,0T |
| 3T | Amarilla | 60 mm | 3,0T | 2,4T | 6,0T | 5,4T | 4,2T | 3,0T |
| 5T | Roja | 75 mm | 5,0T | 4,0T | 10,0T | 9,0T | 7,0T | 5,0T |
| 8T | Azul | 90 mm | 8,0T | 6,4T | 16,0T | 14,4T | 11,2T | 8,0T |
| 10T | Naranja | 100 mm | 10,0T | 8,0T | 20,0T | 18,0T | 14,0T | 10,0T |
